Characteristics

Advantages

• Extruded aluminum front and top — For a unique, striking look
• Extremely sturdy — Impact and rust resistant
• Available in three watt densities — Meets all your needs
• Faux sections, pedestals and finished backs available — Customizable installation

COLORS

• Standard: white
• Luxury finish: anodized aluminum (see price list)
• ORORA (optional): refer to the Orora section

FINISH

• Epoxy-polyester powdercoat or anodized aluminum finish

MANUFACTURING

• Dimensions: 4 3/8 in. x 6 3/4 in.
• Solid 20-gauge steel cabinet and extremely resistant extruded aluminum front cover with a thickness equivalent to 10 gauge
• Front air intake and top air discharge (bottom air intake available on demand [BT])
• Thermal protection with automatic reset
• Full-length wireway
• Pencil-proof openings of less than 1/4 in. prevent foreign objects from entering the unit

ELEMENTS

• Double tubular elements, stainless steel sheathed with boxed aluminum fins for improved heat dissipation; the elements are securely fastened at their centres, floating in nylon sleeves at each end, eliminating expansion and contraction noises

CONTROL

• Wall thermostat (not included) – the use of an electronic thermostat is strongly recommended
• Built-in tamper-proof thermostat accessible without removing front grille, installed in the left or right junction box (optional)
• Low voltage relay kit installed in the left or right junction box (optional)
• Multiple integrated controls can be installed in the same baseboard

INSTALLATION

• Surface mounted
• Wall or floor mounted with or without pedestal kit (optional)
• At least 3 in. from the floor (models with BT option only)
• Wiring compartments at both ends of unit
• For a continuous look, custom blank sections with a simple attachment system are available (optional)

WARRANTY

• Three years
