Characteristics

Advantages

• Rugged casing — Specifically designed for high-traffic public areas
• Perfect for public spaces — Schools, shopping centres, hospitals, etc.
• 6 mm (1/4 in.) openings that restrict access to the elements — Safer casing
• Available in three watt densities — Meets all your needs
• Blank sections, pedestals and finished backs available — Customizable installation

COLORS

• Standard: white
• ORORA (optional): refer to the Orora section

FINISH

• Epoxy-polyester powdercoat

MANUFACTURING

• 18-gauge steel cabinet and 16-gauge steel front panel
• Front air intake and top air discharge
• Thermal protection with automatic reset
• Full-length wireway

ELEMENT

• Single tubular, stainless steel sheathed element with boxed aluminum fins for improved heat dissipation; the element is securely fastened at its centre, floating in nylon sleeves at each end, eliminating expansion and ontraction noises

CONTROL

• Wall thermostat (not included) – the use of an electronic thermostat is strongly recommended
• Built-in tamper-proof thermostat accessible without removing front grille, installed in the left junction box only (optional)
• Low voltage relay kit installed in the left or right junction box (optional)

INSTALLATION

• Surface mounted
• Wall or floor mounted with or without pedestal kit (optional)
• Wiring compartments at both ends of unit
• Blank sections (custom lengths) and accessories are available for a continuous look (optional)

WARRANTY

• Three years
