STF362XU

CONCERTO EXPANSION, Expansion Unit

Ideal for big projects


CONCERTO EXPANSION units make it easy to cover large rooms requiring more than 15 A. Install these expansion units to avoid having to use several thermostats. Each unit controls a section of the floor based on the main thermostat’s commands, ensuring efficient and uniform temperature management.

Characteristics

ADVANTAGES
  • Easy daisy-chain connection — Maximum distance of 80 ft (25 M) between two consecutive units
  • Compatible with concerto thermostats
  • Each unit can handle 15 A — The number of units required depends on the total load of the installation
  • Ground fault circuit interrupter (GFCI class A) — Protects users and the installation
COLOR
  • White
FINISH
  • Molded plastic
MANUFACTURING
  • Fitted with ground fault circuit interrupter (GFCI) and a test indicator light.
  • Terminal block connection / DPST with 2-pole disconnects

POWER AND VOLTAGE
  • Maximum of 1800 W @ 120 V
  • Maximum of 3120 W @ 208 V
  • Maximum of 3600 W @ 240 V
WARRANTY
  • Three years

Documents

STF362XU

Specsheet

PDF

Download (opens in a new tab)

STF362XU

Technical drawings

PDF

Download (opens in a new tab)

STF362XU

Quickstart guide

PDF

Download (opens in a new tab)

STF362XU

Shop drawings

ZIP

Download (opens in a new tab)

Specifications
